Scalability 1S Only
PCI Express Revision 5.0 and 4.0
PCI Express Configurations Up to 1x16+2x4, 2x8+2x4, 1x8+4x4
Max # of PCI Express Lanes 24
Thermal Solution Specification PCG 2022C
Max Operating Temperature 105 °C
Package Size 45 mm x 37.5 mm
Intel® Gaussian & Neural Accelerator 3.5
Intel® Thread Director Yes
Intel® Speed Shift Technology Yes
Intel® Turbo Boost Max Technology 3.0 Yes
Intel® Turbo Boost Technology 2.0
Intel® Hyper-Threading Technology No
Intel® 64 Yes
Instruction Set 64-bit
Instruction Set Extensions Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2
Idle States Yes
Enhanced Intel SpeedStep® Technology Yes
Thermal Monitoring Technologies Yes
Intel® Volume Management Device (VMD) Yes
Intel vPro® Eligibility Intel vPro® Enterprise
Intel® Threat Detection Technology (TDT) Yes
Intel® Active Management Technology (AMT) Yes
Intel® Standard Manageability (ISM) Yes
Intel® Remote Platform Erase (RPE) Yes
Intel® One-Click Recovery Yes
Intel® Secure Key Yes
Intel® Control-Flow Enforcement Technology Yes
Intel® Total Memory Encryption - Multi Key Yes
Intel® AES New Instructions Yes
Intel® Trusted Execution Technology Yes
Execute Disable Bit Yes
Intel® OS Guard Yes
Intel® Boot Guard Yes
Mode-based Execute Control (MBEC) Yes
Intel® Stable IT Platform Program (SIPP) Yes
Intel® Virtualization Technology with Redirect Protection (VT-rp) Yes
Intel® Virtualization Technology (VT-x) Yes
Intel® Virtualization Technology for Directed I/O (VT-d) Yes
Intel® VT-x with Extended Page Tables (EPT) Yes
socketFCLGA1851
tdp65 W
Product Collection Intel® Core™ Ultra Processors (Series 2)
Code Name Products formerly Arrow Lake
Vertical Segment Desktop
Processor Number 265
Overall Peak TOPS (Int8) 33
Total Cores 20
# of Performance-cores 8
# of Efficient-cores 12
# of Low Power Efficient-cores 0
Total Threads 20
Max Turbo Frequency 5.3 GHz
Intel® Turbo Boost Max Technology 3.0 Frequency 5.3 GHz
Performance-core Max Turbo Frequency 5.2 GHz
Efficient-core Max Turbo Frequency 4.6 GHz
Performance-core Base Frequency 2.4 GHz
Efficient-core Base Frequency 1.8 GHz
Cache 30 MB Intel® Smart Cache
Total L2 Cache 36 MB
Maximum Turbo Power 182 W
Intel® Deep Learning Boost (Intel® DL Boost) on CPU Yes
AI Software Frameworks Supported by CPU OpenVINO™, WindowsML, DirectML, ONNX RT, WebNN
CPU Lithography TSMC N3B
Marketing Status Launched
Embedded Options Available Yes
AV1 Encode/Decode Yes
Intel® Quick Sync Video Yes
# of Displays Supported 4
Device ID 0x7D67
Intel® Deep Learning Boost (Intel® DL Boost) on GPU Yes
AI Software Frameworks Supported by GPU OpenVINO™, WindowsML, DirectML, ONNX RT, WebGPU
NPU NameIntel® AI Boost
NPU Peak TOPS (Int8) 13
Sparsity Support Yes
Windows Studio Effects Support Yes
AI Software Frameworks Supported by NPU OpenVINO™, WindowsML, DirectML, ONNX RT, WebNN
Direct Media Interface (DMI) Revision 4
Max # of DMI Lanes 8
Intel® Thunderbolt™ 4 Yes
Use Conditions PC/Client/Tablet, Workstation
Max Memory Size (dependent on memory type) 256 GB
Max # of Memory Channels 2
ECC Memory Supported Yes
GPU NameIntel® Graphics
Graphics Base Frequency 300 MHz
Graphics Max Dynamic Frequency 1.95 GHz
GPU Peak TOPS (Int8) 8
Graphics Output eDP1.4b, DP 2.1 UHBR20, HDMI 2.1 FRL
Xe-cores 4
Max Resolution (HDMI)4096 x 2304 @ 60Hz (HDMI 2.1 TMDS) 7680 x 4320 @ 60Hz (HDMI 2.1 FRL)
Max Resolution (DP)7680 x 4320 @ 60Hz
Max Resolution (eDP - Integrated Flat Panel)3840 x 2400 @ 120Hz
DirectX* Support 12
OpenGL* Support 4.5
OpenCL* Support 3
H.264 Hardware Encode/Decode Yes
H.265 (HEVC) Hardware Encode/Decode Yes
memoryTypeDDR5
